NC press break
Fiber Lasertech represents a revolutionary technological breakthrough in modern industrial manufacturing, offering unparalleled precision in cutting, marking, and metal processing. Integrating energy-efficient fiber laser sources, high-speed CNC control systems, and advanced automation, it transforms manufacturing processes to be faster and flawless. From a CEO's perspective, it significantly reduces operational costs, minimizes material waste, and vastly increases production throughput. Its performance is exceptional for precision cutting on metals like stainless steel, aluminum, mild steel, and brass. By ensuring low maintenance costs, long-term durability, and a rapid Return on Investment, Fiber Lasertech serves as a highly profitable strategic asset, driving long-term corporate growth and securing a strong competitive edge in the market.
Technical Parameters
Model | Unit | BLT press 01 | ||
Nominal Pressure | KN | 1600 | ||
Table length | mm | 3200 | ||
Distance between housings | mm | 2550 | ||
Throat depth | mm | 400 | ||
Stroke | mm | 200 | ||
Open height | mm | 450 | ||
Main Power | KW | 11 | ||
Dimension (LengthxWidthxHeight) | mm | 3600x2000x2600 | ||
Weight | KG | 8300 | ||
X back gauge | mm | 500 | ||
X travel | Speed | mm/s | 350 | |
Accuracy | mm | ±0.01 | ||
Y travel | Speed | Fast down | mm/s | 80 |
Pressing | 10 | |||
Return | 80 | |||
Accuracy | mm | ±0.01 | ||
Main Specification
Name | Brand |
NC controller | E21 |
Main motor | Siemens, Germany |
Main electrics | Schneider, France |
Oil Pump | Sunny/First, America |
Valve | Rexroth, Germany |
Oil Cylinder | Yuhua,China |
Connector | EBM,Germany |
Ball screw and linear guide | HIWIN/HAWKKING,Taiwan |
Quick Clamp | Jiejun,China |
Punch & die | Welda,China |
